Mark-10 Series 5 Digital Force Gauge, 1000 lbF (M5-1000)
$1,665.00
Mark-10 Series 5 advanced digital force gauge, 1000 lbF / 500 kgF / 5 kN capacity, S-beam load cell.
Description
Mark-10 Series 5 advanced digital force gauge for tension and compression testing. Directly compatible with Mark-10 test stands, grips, and MESUR® Lite data acquisition software.
| Capacity | 1000 lbF / 16000 ozF / 500 kgF / 5 kN |
| Sampling rate | 7,000 Hz |
| Data output rate | 500 Hz |
| Accuracy | ±0.1% of full scale |
| Resolution | 1/5000 |
| Data memory | 1,000 readings with statistics (min, max, mean, std. dev.) |
| Data output | USB, RS-232, Mitutoyo (Digimatic), analog |
| Overload protection | 200% of rated capacity |
Documentation
Download Series 5 User’s Guide (PDF) — Official Mark-10 manual for Series 5 digital force gauges (setup, operation, and calibration).
