On-Site Calibration at Your Facility
Instrument Calibration Solutions (ICS) performs accredited on-site calibration at your facility, so your gages, meters and measuring systems stay in production instead of in a shipping box. Technicians from our A2LA-accredited labs in Aliquippa, PA and Clayton, OH, plus our mobile calibration lab based in Canton, OH, serve customers in Pennsylvania, Ohio, West Virginia, Indiana, Kentucky, Michigan and Iowa. Every calibration comes with a certificate showing as-found/as-left data, traceable to NIST.
With on-site service you also get a professional metrologist on hand to answer questions about your equipment, and our technicians can complete maintenance checks and repairs while they are there (repair service is limited to parts availability).
What We Calibrate On-Site
Field calibration is listed on our ISO/IEC 17025 scopes of accreditation for these equipment types:
- Dimensional: micrometers and calipers up to 40 in, optical comparators (linear accuracy, angle, X/Y perpendicularity, magnification), video measuring systems, and granite surface plates (flatness and repeat reading, up to 192 in diagonal)
- Torque: torque wrenches and torque measuring equipment from 4 lbf·in to 600 lbf·ft
- Electrical: DC and AC voltage, current, resistance and capacitance, oscilloscopes, clamp meters, and thermocouple/RTD simulation for process instruments
- Temperature: digital and analog thermometers, and temperature surveys of water baths, refrigerators, freezers, chambers and ovens
- Pressure (Aliquippa, PA scope): pressure, vacuum and water-column gauges and transducers up to 10,000 psi
- Time and frequency: frequency counters, stopwatches and timers
Force gauges, load cells and dynamometers are calibrated in our labs, where our accredited force capability runs up to 100,000 lbf. See the full details on our accreditation and scope page.
On-Site vs. In-Lab Calibration
| On-site | In our lab | |
|---|---|---|
| Downtime | Equipment stays at your facility; calibrated where it is used | Equipment is shipped or dropped off; expedited service available |
| Best for | Large instrument counts, fixed equipment (surface plates, optical comparators, video systems, chambers) | Force and load cells, items needing a controlled environment or the lowest uncertainty |
| Shipping risk | None | Packed and shipped via UPS, FedEx or USPS, or delivered in person |
| Uncertainty | Can be larger than lab CMCs because of site conditions | Smallest achievable uncertainty (CMC) on our scope |
How On-Site Calibration Works
- Send your equipment list. Request a quote or call your nearest lab: Aliquippa, PA at 724-846-0136 or Clayton, OH at 937-836-0064.
- We schedule the visit around your production and audit dates.
- Technicians calibrate on-site, recording as-found and as-left data for every instrument.
- Certificates are delivered and available any time in our free ICS LIVE portal, along with recall dates for your next calibration.
Frequently Asked Questions
What can ICS calibrate on-site?
Dimensional gages, optical comparators, video measuring systems, surface plates, torque wrenches, electrical test equipment, thermometers and thermal equipment, and (from our Aliquippa lab) pressure instruments. These are all listed for field calibration on our A2LA scopes.
Are on-site calibrations accredited?
Yes, for every parameter our ISO/IEC 17025 scope lists as available for field calibration. On-site measurement uncertainty can be larger than our lab values because of site conditions, and the certificate reports the uncertainty actually achieved.
Which areas do your technicians cover?
Pennsylvania, Ohio, West Virginia, Indiana, Kentucky, Michigan and Iowa, from our labs in Aliquippa, PA (Pittsburgh area) and Clayton, OH (Dayton area) and our mobile lab based in Canton, OH.
Can you calibrate force gauges and load cells on-site?
Force gauges, load cells and dynamometers are calibrated in our accredited labs. See force measurement and calibration for ranges and turnaround.
How do I track my certificates and due dates?
Every customer gets free access to ICS LIVE, our online portal for current and past calibration certificates, status updates and calibration recalls.
