Mark-10 Series 5 Digital Force Gauge, 100 lbF (M5-100)
$1,225.00
Mark-10 Series 5 advanced digital force gauge, 100 lbF / 1600 ozF / 50 kgF / 500 N capacity.
Description
Mark-10 Series 5 advanced digital force gauge for tension and compression testing. Directly compatible with Mark-10 test stands, grips, and MESUR® Lite data acquisition software.
| Capacity | 100 lbF / 1600 ozF / 50 kgF / 500 N |
| Sampling rate | 7,000 Hz |
| Data output rate | 500 Hz |
| Accuracy | ±0.1% of full scale |
| Resolution | 1/5000 |
| Data memory | 1,000 readings with statistics (min, max, mean, std. dev.) |
| Data output | USB, RS-232, Mitutoyo (Digimatic), analog |
| Overload protection | 200% of rated capacity |
Documentation
Download Series 5 User’s Guide (PDF) — Official Mark-10 manual for Series 5 digital force gauges (setup, operation, and calibration).
