Mark-10 Series 5 Digital Force Gauge, 0.25 lbF (M5-025)

Description

Mark-10 Series 5 advanced digital force gauge for tension and compression testing. Directly compatible with Mark-10 test stands, grips, and MESUR® Lite data acquisition software.

Typical applications: The M5-025’s 0.25 lbF range makes it a natural fit for electronics assembly QA, miniature component testing, and other applications where only a few pounds of force are involved.

Frequently Asked Questions

Q: What’s the accuracy of the M5-025?
A: The Series 5 is rated at ±0.1% of full scale with 1/5000 resolution.

Q: What data output options does the M5-025 support?
A: USB, RS-232, Mitutoyo (Digimatic), and analog output are all supported, so it drops into most existing data acquisition or SPC setups without an adapter.

Q: Is the M5-025 compatible with Mark-10 test stands?
A: Yes — it’s directly compatible with Mark-10 motorized and manual test stands, along with Mark-10 grips, fixtures, and MESUR Lite data acquisition software.

Q: What’s the overload protection on the M5-025?
A: The gauge is protected to 200% of its rated capacity.

Q: How much data can the M5-025 store?
A: It stores up to 1,000 readings on board, with built-in statistics (min, max, mean, and standard deviation) calculated automatically.

Documentation
Download Series 5 User’s Guide (PDF) — Official Mark-10 manual for Series 5 digital force gauges (setup, operation, and calibration).
