Mark-10 Series 3 Digital Force Gauge, 0.25 lbF (M3-025)

Description

Mark-10 Series 3 basic digital force gauge for tension and compression testing. Directly compatible with Mark-10 test stands, grips, and MESUR® Lite data acquisition software.

Typical applications: With a 0.25 lbF capacity, the M3-025 is well suited to low-force work such as PCB connector insertion/extraction, medical device component testing, spring-rate verification, and small snap-fit or clip testing.

Frequently Asked Questions

Q: What’s the capacity of the M3-025?
A: It’s rated for 0.25 lbF / 100 gF / 1 N.

Q: What’s the overload protection on the M3-025?
A: It’s protected to 200% of rated capacity.

Q: What software does the M3-025 include?
A: MESUR® Lite included.

Q: How fast does the M3-025 sample data?
A: It samples at 2,000 Hz.

Q: What kind of display does the M3-025 have?
A: Backlit graphic LCD with analog load bar.

Q: Does the M3-025 support pass/fail testing?
A: Yes — programmable, with pass/fail indicators.

Documentation
Download Series 3 User’s Guide (PDF) — Official Mark-10 manual for Series 3 digital force gauges (setup, operation, and calibration).
