Imada DST-110A Digital Force Gauge (110 lbf)
$655.00
Imada DST-110A digital force gauge, 110 lbf / 50 kgf / 500 N capacity, complete kit.
Description
The Imada DST digital force gauge is an economical, easy-to-use gauge with a large backlit LCD display and user-friendly menu operation. Sold as a complete kit with carrying case, six attachments, and AC adapter/charger.
| Capacity | 110 lbf / 50 kgf / 500 N |
| Accuracy | ±0.2% F.S., ±1 LSD |
| Sampling rate | 30,000/second |
| Overload capacity | 200% F.S. |
| Outputs | USB, RS-232C |
| Power | Rechargeable Ni-MH battery or AC adapter |
Typical applications: The DST-110A’s 110 lbf range is suited to industrial fastener testing, automotive component checks, and compression testing of gaskets and rubber parts.
Documentation
Imada DST Digital Force Gauge — official product page — specifications and accessories for the DST series.
Additional information
| Weight | 1.5 lbs |
|---|---|
| Dimensions | 10 × 6 × 4 in |
